Build a Future-Ready GPU Server: How to Choose the Right NVIDIA Hardware & Infrastructure?
Are you planning to build a GPU-accelerated server? This guide breaks down the essential NVIDIA components, server design requirements, PCIe vs. SXM considerations, and best practices for powering AI, HPC, and inference workloads; from single-GPU nodes to production-ready clusters!
Why build a GPU server instead of buying a fully assembled system?
As AI adoption accelerates, organizations increasingly need flexible and scalable GPU-accelerated compute nodes. Buying a pre-built OEM server is great for turnkey deployments—but building your own GPU server gives you more control over cost, performance, and upgrade paths.
Building your own GPU server offers several advantages:
- Cost efficiency — mix new and refurbished GPUs for maximum value
- Customizability — choose your own storage, cooling, networking, and PCIe layout
- Scalability — add GPUs over time instead of buying a full new server
- Workload alignment — optimize specifically for AI training, inference, or HPC
Catalyst supports both approaches, offering new and refurbished NVIDIA data-center GPUs that can be deployed in standalone builds or integrated into full server architectures.
Understanding NVIDIA GPU product lines.
NVIDIA’s data-center GPU ecosystem is organized into several core product families. Each line is optimized for a specific class of workloads—from massive AI training clusters to energy-efficient inference, HPC research, visualization, and workstation compute. The NVIDIA products in the Catalyst catalog represent the entire spectrum of modern GPU infrastructure.
1. NVIDIA H100: State-of-the-art for AI training, LLMs & HPC
The NVIDIA H100—powered by the Hopper architecture—is the highest-performance data-center GPU available today. With industry-leading FP8/BF16 throughput, 3 TB/s of HBM3 memory bandwidth, and advanced security features, H100 is built for training large language models, running high-fidelity simulations, and powering multi-GPU HPC clusters.
Catalyst carries several H100 variants:
- NVIDIA H100 SXM5 80GB Accelerator — ideal for dense NVLink-enabled AI training servers.
- NVIDIA H100 Tesla 80GB x16 PCIe GPU — engineered for large-scale AI, HPC, and compute workloads.
In general, SXM-based H100 systems deliver the highest performance due to higher power budgets and NVLink support,
while PCIe variants are ideal for standard enterprise server deployments.
2. NVIDIA H100 SXM Server: Turnkey AI Supercomputer Node
Beyond individual GPUs, Catalyst also offers a complete 8× H100 SXM server—a fully integrated AI training system designed for large-scale compute. This platform combines eight H100 SXM modules using high-speed NVLink and NVSwitch fabrics, enabling GPUs to communicate at extremely low latency and high bandwidth.
- Built for LLM training, RAG pipelines & multi-node scaling
- Full NVLink topology for synchronized multi-GPU acceleration
- Ideal for research labs, AI teams & enterprises deploying private LLMs
- Offers best-in-class performance per rack unit for training clusters
Explore the complete system:
NVIDIA H100 8×80GB SXM Server | AI & HPC Acceleration
This configuration is typically used as the building block for multi-node GPU clusters—allowing distributed training of multimodal models and ultra-large transformers.
3. NVIDIA L40 & L40S: The universal GPU for inference, VDI & graphics
The L40/L40S GPUs are NVIDIA’s “universal accelerators,” designed to handle modern inference, rendering, graphics, and mixed compute workloads. They deliver excellent performance-per-watt and are favored in enterprise environments where efficiency and versatility matter.
- Excellent for AI inference & real-time prediction
- Supports VDI and GPU-accelerated virtual workstations
- Great for rendering, visualization & media pipelines
Browse available L40/L40S units via the
Catalyst NVIDIA catalog.
4. NVIDIA Tesla V100: Proven, affordable GPU performance
The Tesla V100 remains one of the most popular GPUs in AI and HPC labs because of its strong FP32/FP64 performance and tensor compute capabilities. For many organizations, V100 nodes complement newer Hopper systems by handling fine-tuning, classical ML workloads, and medium-scale inference.
- NVIDIA Tesla V100 32GB PCIe (Refurbished) — a cost-effective option for scalable GPU capacity.
5. NVIDIA RTX Workstation GPUs: Hybrid AI, visualization & creation
For power-users, design teams, and scientific visualization groups, RTX workstation GPUs offer a blend of large memory, FP8-accelerated compute, and real-time visualization capabilities. They are excellent for “development first, scale later” workflows.
- NVIDIA RTX PRO 6000 Blackwell Max-Q — ideal for simulation, content creation, and local AI model development.
If you’re planning to scale beyond a single GPU server into multi-node clusters, high-speed fabrics, and workload scheduling, explore our deeper guide: Deploying NVIDIA GPUs for AI & HPC Workloads⚡️.
Related NVIDIA products & datasheets:
For the most accurate specs—power envelopes, thermal limits, memory bandwidth, form-factor requirements—refer to these official NVIDIA datasheets:
Mapping workloads to NVIDIA GPUs
Choosing the right GPU begins with understanding your workload. Here’s how the most common use cases map to the GPUs you carry.
| Workload | Recommended GPUs | Notes |
|---|---|---|
| Large-scale AI training / LLMs | H100 SXM, H100 PCIe | Best performance for FP8, BF16, and multi-GPU scaling |
| Enterprise inference / VDI | L40, L40S | Highly efficient, lower power draw, excellent density |
| HPC simulation / research | H100, V100 | Strong FP64/FP32 performance |
| Visualization / rendering / AI workstations | RTX Pro series | Great for hybrid creative + compute workloads |
Server infrastructure requirements
GPU servers place unique demands on system architecture, especially when running multi-GPU workloads. When building your own system, make sure the following elements align:
- Dual-socket CPU platform — prevents bottlenecks and delivers more PCIe lanes
- Redundant power supplies — GPU-heavy systems draw significant wattage
- High-airflow chassis — GPUs generate concentrated heat
- PCIe Gen4/Gen5 support — critical for modern GPUs like H100
- Sufficient physical clearance — double-width GPUs (PCIe) need space
PCIe vs. SXM GPUs: What should you choose?
Most NVIDIA data-center GPUs come in one of two physical formats:
PCIe GPUs
- Work in standard enterprise servers
- Easier to upgrade or mix GPUs
- More compatible with refurbished server builds
SXM GPUs
- Higher performance (more bandwidth, higher power TDP)
- Supports NVLink fabric for multi-GPU scaling
- Requires OEM servers designed for SXM modules
In your catalog, both formats are represented—making it easy to match customers with the right hardware.
Power, cooling & airflow considerations
GPUs are sensitive to heat, and servers can throttle performance dramatically under thermal stress. When building a GPU server:
- Ensure your PSU supports peak GPU load (H100 can draw >300W)
- Use high-static pressure fans
- Maintain front-to-back airflow (no mixed airflow chassis)
- Position servers in cool zones of the rack
Storage & networking for GPU compute
AI and HPC workloads place huge demands on I/O. A balanced GPU server should include:
- NVMe SSDs — for high-throughput data access
- RDMA-capable networking (InfiniBand or RoCE)
- High-speed internal buses — PCIe Gen4/Gen5
- Enough RAM to feed GPUs, especially for LLMs
Example GPU server configurations
Here are three example build patterns based on GPUs Catalyst currently offers.
| Use Case | Configuration | Relevant GPUs |
|---|---|---|
| AI Training Node | Dual-CPU, 4–8 GPUs, NVMe, 100GbE | H100 SXM, H100 PCIe |
| Inference / Edge Platform | Single or Dual-CPU, 1–2 GPUs, mid-range NVMe | L40, V100 |
| Visualization / Hybrid AI | Workstation or rackmount with single high-end GPU | RTX Pro 6000 Blackwell |
Frequently asked questions
How many GPUs should I plan for in a future-ready server?
It depends on your workload and growth curve. Many organizations start with a 1–2 GPU server for pilots and smaller inference jobs, then move to 4–8 GPU nodes for serious training or large-scale experimentation. If you’re planning LLM training, dense HPC workloads, or multi-tenant GPU clusters, 8× GPU systems such as an H100 8×80GB SXM server often become the standard building block for a larger cluster.
What’s the difference between building my own GPU server and buying an OEM system?
OEM systems arrive fully integrated and validated, which is ideal if you want a turnkey experience. Building your own GPU server, however, gives you more flexibility: you can mix new and refurbished NVIDIA GPUs, choose the exact storage and networking stack, and incrementally expand over time. Many teams use a hybrid approach—buying a few OEM nodes while also building custom GPU hosts for specific AI, HPC, or lab environments.
Do I really need H100, or is something like L40 or V100 enough?
Not every workload needs H100-class performance. If you’re training very large models, running complex simulations, or building a long-term LLM platform, H100 (especially in SXM form factor) is usually the right choice. For high-volume inference, VDI, and mixed graphics/AI workloads, L40 or L40S can be more power-efficient and cost-effective. For labs and cost-optimized clusters, V100 still offers excellent value, especially when sourced as certified refurbished hardware.
How do I make sure my power and cooling are sufficient for NVIDIA GPUs?
Start by checking the official TDP and thermal requirements for your GPUs, then confirm that your power supplies, rack power budget, and cooling design can handle peak draw—not just idle or average load. In practice, that often means:
- Redundant PSUs sized for worst-case GPU and CPU load
- High-static-pressure fans and clear front-to-back airflow
- Rack-level planning so hot nodes aren’t stacked in one thermal hotspot
Catalyst can help you review these details before you purchase hardware so you don’t run into unexpected throttling or derating after deployment.
Can Catalyst help design and validate our NVIDIA GPU infrastructure?
Yes. Catalyst works with your team to turn business requirements into a practical GPU architecture. We can help you choose between H100, L40, V100, and RTX options, map them to the right server platform, and design a balanced configuration across power, cooling, storage, and networking. If you’d like, we can also validate a reference build before you scale it out across the data center.
Can Catalyst get NVIDIA products to us quickly?
In most cases, yes. Catalyst maintains an extended network of OEM, distributor, and refurb partners, which means we can often source NVIDIA GPUs and complete GPU servers faster than standard lead times. If you have a tight project window or need to get a lab up and running quickly, request a quote now and we’ll work to match your deadline with the best available options.
Can Catalyst source a different NVIDIA product than what’s listed on the site?
Absolutely. The NVIDIA products on our website represent a curated subset of what we can deliver. Through our distribution and OEM network, we can often source alternate GPU SKUs, different memory sizes, or specific server platforms that align with your standards. Just tell us what you’re looking for—or what workload you’re trying to support—and we’ll track down the right NVIDIA option for you.
